Backed by a full one year warranty. Reconditioned by AVO certified technicians! Test reports included. Ask us about getting store credit for your old unit! Custom configurations available upon request. The product image shown is for identification purposes only. The item you receive may have cosmetic differences unrelated to function. Such differences may include version, series, frame color or design, lid color or design, label material, label color, label modifications, service stamps, scuffs, scratches, etc.
Specs are as follows:
--Magnetic Motor Contactor, Nema Size 0, 18 Amps, 3 Poles, 480VAC Coil, Full Voltage 600VAC, Open Style No Enclosure, Across the Line Starting and Stopping, Single Speed, Non-Reversing, Max HP Ratings (3 Phase): 3 @ 200VAC, 3 @ 230VAC, 5 @ 460VAC, 5 @ 575VAC
Specificationss
| Amperage | 18 |
|---|---|
| Application | Full Voltage |
| Coil type | Magnetic |
| Coil voltage | 480 VAC |
| Manufacturer | Square-D |
| Maximum rating | 3 HP @ 200VAC, 3 HP @ 230VAC, 5 HP @ 460VAC, 5 HP @ 575VAC |
| Nema size | 0 |
| Phase | 3 |
| Poles | 3 |
| Reversing or non reversing | Non-Reversing |
| Standard lug type | Line and Load |
| Voltage max | 600 |
| Warranty | One Year |
